SD12 Mini Excavator – Powerful, Flexible & Built for Professional Performance
The SENDEMACH SD12 is a 1.2-ton compact mini excavator engineered for construction contractors, rental businesses, landscapers, and agricultural users who need a reliable, versatile, and fuel-efficient machine. Powered by the Yanmar 3TNV70 diesel engine, the SD12 delivers exceptional performance, low noise, reduced emissions, and long service life.
Designed with a retractable (expandable) chassis, the SD12 easily adapts to narrow working spaces while providing increased stability when fully extended. The two-speed travel motor allows operators to switch between low-speed torque and high-speed mobility for faster jobsite movement.
Its reinforced boom, precise hydraulic system, and wide range of attachments make the SD12 the ideal micro excavator for tough jobs in tight areas.
Key Features
Yanmar 3TNV70 Engine — World-class reliability, strong torque, low fuel consumption
Retractable Chassis — Track width adjustable for narrow access or improved stability
Two-Speed Travel Function — Efficient movement on different terrains
High-Precision Hydraulic System — Smooth, accurate control for professional performance
Optional Attachments — Buckets, auger, ripper, rake, thumb, quick hitch, breaker, etc.
Compact & Easy to Transport — Fits on small trailers and in tight job sites
Reinforced Structure — Durable chassis and boom built for long-term use
Typical Applications
Residential and commercial construction
Landscaping & garden work
Trenching for utilities and irrigation
Farmland and orchard tasks
Small demolition and material handling
Rental fleets and urban construction projects
Technical Highlights
Operating weight: 1,200 kg (depends on configuration)
Engine: Yanmar 3TNV70, EPA/EU-certified
Undercarriage: Retractable (expandable track width)
Travel motor: Two-speed
Bucket capacity: 0.03–0.04 m³
Hydraulic pump: High-efficiency gear or plunger pump
Track type: Durable rubber tracks
Optional: Canopy, hydraulic thumb, swing boom, quick hitch, closed cabin, upgraded pump
Why Choose SENDEMACH SD12?
Trusted professional manufacturer of mini excavators
Strict international quality standards
Strong global after-sales support
Custom configurations available for local markets
Competitive pricing for distributors and dealers
Tags:
Technical parameter
| Operating weight（T） | 1.2 |
| Bucket capacity(m³） | 0.03 |
| Engine model | YANMAR 3TNV70 |
| Rated power (kw/r/min) | 10.3/2200 |
| Authentication | Euro V |
| Max.flow (L/min) | 22 |
| Working pressure (Mpa) | 17.5 |
| Fuel tank capacity (L) | 13 |
| Hydraulic oil tank capacity (L) | 13 |
| Travel speed (km/h) | 1.2/2.4 |
| Swing speed (r/min) | 10.5 |
| Max. climbing degree (%) | 58 |
| Arm digging force(KN) | 6.5 |
| Bucket digging force (KN) | 11 |
| Average grounding pressure (Kpa) | 31 |
| Largest traction(KN) | 13 |
| A-Overall length (mm) | 3070 |
| B-Overall width (mm) | 880/1100 |
| C-Overall height (to top of boom)(mm) | 1170 |
| D-Overall height (to top of cab)(mm) | 2400 |
| E-Counterweight ground clearance(mm) | 400 |
| F-Min. ground clearance (mm) | 130 |
| G-Tail swing radius (mm) | 550 |
| H-Track ground length(mm) | 1080 |
| J-Track length (mm) | 1400 |
| K-Track gauge (mm) | 670（920Extended） |
| L-Track width (mm) | 850-1100 |
| M-Track shoe width (mm) | 180 |
| N-Turntable width (mm) | 850 |
| O-Max. digging height (mm) | 3060 |
| P-Max. dumping height (mm) | 2080 |
| Q-Max. digging depth (mm) | 1830 |
| R-Max. vertical wall digging depth (mm) | 1610 |
| T-Max. digging reach (mm) | 3540 |
| U-Max. digging reach at ground level (mm) | 3500 |
| V-Min. swing radius (mm) | 1560 |
| X-Distance between center of rotation and tail length (mm) | 550 |
| Y-Track shoe thickness (mm) | - |
| Z-Height of counterweight (mm) | 735 |
| A1-Ground length (in transportion)(mm) | 1660 |
| Arm length (mm) | 890 |
| Boom length (mm) | 1500 |
| Deflection angle left°/right° | 50°/70° |
| Maximum dozing height/depth (mm) | 168/275 |
