Products Description
| Engine Specifications | Manufacturer | - | Yanmar | Dimensions | Boom Length | mm | 3,700 |
| Model | - | 4TNV98 | Arm Length | mm | 1,670 | ||
| Emissions Standard | - | China II | Bucket Capacity (STD) | m³ | 0.32 | ||
| Rated Power (Gross Power) | KW/hp/ps/pm | 36212200 | Overall Length | mm | 6,090 | ||
| Rated Power (Net Power) | KW/hp/ps/rpm | 342/2200 | |||||
| Maximum Torque | NM/pm | 200.8/1400 | Overall Height (Boom) | mm | 2710 | ||
| Displacement | CC | 3054 | Overall Height (Cab) | mm | 2,510 | ||
| Number of Cylinders × Bore × Stroke | EA-mm | 4-94X110 | Track Ground Length (Wheelbase, Track Width) | mm | 2,130 | ||
| Battery | EA-V×AH | 1-93 | Track Length | mm | 2730 | ||
| Starter Motor | V/kW | 12/3.0 | Counterweight Ground Clearance | mm | 745 | ||
| Alternator | VA | 12/100 | |||||
| Performance Specifications | Swing Speed | rpm | 10.5 | Tail Swing Radius | mm | 1,725 | |
| Swing Torque | kNm | 17.94 | Overall Width | mm | 2,260 | ||
| Travel Speed | km/hr | 243/3.95 | Track Plate Width | mm | 450 | ||
| Gradeability | deg | 35 | Track Gauge | mm | 1,750 | ||
| Maximum Tractive Force | ton | 6.75 | |||||
| Bucket Digging Force (ISO) | ton | 5.04 | Minimum Ground Clearance | mm | 290 | ||
| Dishman Digging Force (ISO) | ton | 3.52 | Other | Fuel Tank Capacity | L | 142 | |
| Chassis Specifications | Idler Wheel | EA(Each Side) | 1 | Hydraulic Oil Tank Capacity (System) | L | 128 | |
| Track Roller | EA(Each Side) | 5 | Engine Oil | L | 92 | ||
| Number of Track Shoes | EA(Each Side) | 38 | Engine Coolant | L | 11.7 | ||
| Ground Pressure | kgf/cm² | 0.33/035 |
