Products Description
| Model | SD240 |
| Operating weight | 22.1 |
| Bucket capacity | 1.1 |
| Engine model | Cummins 6 BT 5.9 |
| Rated power (kw/r/min) | 133/2000 |
| Hydraulic pump model | KPM K3V112DT |
| Max.flow (L/min) | 230*2 |
| Working pressure (Mpa) | 31.4/34.3 |
| Control valve model | KPM K3V112DT |
| Swing motor model | SD220-05.206.01.00（14309122） |
| Travel motor model | SD240-05.204.01.00（13225418） |
| Fuel tank capacity (L) | 360 |
| Hydraulic oil tank capacity (L) | 295 |
| Travel speed (km/h) | 3.3/5.2 |
| Swing speed (r/min) | 10.5 |
| Max. climbing degree (%) | 70 |
| Arm digging force | 110 |
| Bucket digging force (KN) | 139 |
| Average grounding pressure (Kpa) | 47 |
| Largest traction(KN) | |
| A-Overall length (mm) | 9650 |
| B-Overall width (mm) | 2810 |
| C-Overall height (to top of boom)(mm) | 3050 |
| D-Overall height (to top of cab)(mm) | 3007 |
| E-Counterweight ground clearance(mm) | 1075 |
| F-Min. ground clearance (mm) | 465 |
| G-Tail swing radius (mm) | 2850 |
| H-Track ground length(mm) | 3480 |
| J-Track length (mm) | 4174 |
| K-Track gauge (mm) | 2210 |
| L-Track width (mm) | 2810 |
| M-Track shoe width (mm) | 600 |
| N-Turntable width (mm) | 2736 |
| O-Max. digging height (mm) | 9970 |
| P-Max. dumping height (mm) | 7000 |
| Q-Max. digging depth (mm) | 6622 |
| R-Max. vertical wall digging depth (mm) | 5900 |
| T-Max. digging reach (mm) | 9982 |
| U-Max. digging reach at ground level (mm) | 9975 |
| V-Min. swing radius (mm) | 3203 |
| X-Distance between center of rotation and tail length (mm) | 2850 |
| Y-Track shoe thickness (mm) | 10 |
| Z-Height of counterweight (mm) | 1075 |
| A1-Ground length (in transportion)(mm) | 4780 |
| Arm length (mm) | 2925 |
| Boom length (mm) | 5700 |
